Box-type mobile crushing station

The materials are evenly transported to the crusher by the feeder. After the preliminary crushing by the jaw crusher, a closed-circuit system is formed through the circular vibrating screen to realize the circular crushing of the materials. The finished materials are output by the conveyor for continuous crushing operation. The moving crushing station can remove the circular vibrating screen according to the actual production needs, and realize the primary crushing of materials directly. It can be used together with other crushing equipment, and the operation is convenient and flexible.

　　1, the core equipment of the box-type mobile crushing station is the box-type crusher, the crushing efficiency is improved, the output is larger, and the equipment wear is lower. To achieve a multi-purpose machine, operation, running more flexible; In addition to the characteristics of high investment economic efficiency, good quality of crushed stone and low production rate of

　　stone powder, it is equipped with advanced electronic control operating system to ensure the smooth discharge of the whole process, reliable operation, easy operation and energy saving.

　　2, the use of standard flatbed truck chassis to carry the whole set of equipment, feeding system, crushing system, screening system, conveying system and supporting power system layout is reasonable.

　　3, effectively shorten the transportation length by 30%, and design，flexible parking function to ensure that the equipment can quickly enter the working state;

　　4, the use of new centralized lubrication system, unified maintenance toolbox design, maintenance more convenient, save a lot of labor, time costs;

　　5, strong quality, long life, strong adaptability to the environment, no matter any harsh terrain, can be deep into all positions of the work site;

　　6, environmental protection, a major advantage of the equipment, mature design methods, to create an ideal, green production environment.

Model	SMC600	SMC750	SMC900	SMC1060	SMC1200	SMC1300PEX
Transport Size
Length(mm)	8600	9600	11097	13300	15800	9460
Width(mm)	2520	2520	3759	2900	2900	2743
Height(mm)	3770	3500	3500	4440	4500	3988
Alex Weight(kg)	10121	14500	21380	38430	64000	14730
King Pin Weight(kg)	5118	7500	10890	19450	34000	10490
Jaw Crusher
Model	PE	PE	PE	PE	PE	PEX
Feed Opening(mm)	400X600	500X750	600X900	750X1060	900X1200	300X1300
Discharging Hole Setting Range(mm)	40-100	50-100	65-180	80-180	95-225	20-90
Capacity(t/h)	15-60	40-110	90-180	110-380	220-450	30-105
Feeder
Feed Hopper Volume	3	4	7	10	10	3
Hopper Width	2200	2500	3000	3000	3000	2200
Model	ZSW6520	ZSW8530	ZSW9638	ZSW1142	ZSW1349	ZSW8530
Belt Conveyor
Model	B650X6	B800X7	B1000X8	B1000X11	B1200X13	B1000X7
